Online Multiparameter Universal Controller | LH-D6901

Online Multiparameter Universal Controller | LH-D6901

Online Multiparameter Universal Controller  – Overview

This intelligent online controller is widely used in water quality detection and monitoring in sewage plants, waterworks, water stations, surface water and other industries.  Its modular design offers various modules of more than 20 kinds of sensors, which can be combined at will, as well as reserved expansion functions. It can measure 4 parameters similtaneously and has 2 analogue outputs.

Online Multiparameter Universal Controller  – Features

  • High definition color touch screen
  • Strong expansibility and practicability
  • Multiple output modes
  • IP65 waterproof
  • High and low alarm
  • Chinese and English interface
  • Remote communication
  • History record
  • Customisation services

Description

Online Multiparameter Universal Controller | LH-D6901

Name Model No. Measuring range Resolution Accuracy
pH Intelligent Sensor LH-Dph07 0~14pH 0.01 pH ≤±0.02pH
Conductivity Intelligent Sensor LH-DE21 K=0.1 electrode:0.2~200.0μS/cm K=1 electrode: 2~2000μS/cm
K=10 electrode:20μS/cm~20.00mS/cm
0.01 mg/L ±2%F.S.
Dissolved Oxygen Intelligent Sensor LH-DO59 0-20mg/L 0.01 mg/L ±5%
Turbidity Intelligent Sensor LH-DZ09 0-20/ 0-200NTU
0-1000NTU
0-3000NTU
0.01、1NTU
0.1、1NTU
0.1、1NTU
≤5NTU,accuracy≤±0.3NTU; >5NTU,accuracy≤±6%
≤10NTU,accuracy≤±0.5NTU; >10NTU,accuracy≤±8%
Fluorescence Dissolved Oxygen Intelligent Sensor LH-DY06 0~20.00mg/L or 0~200% saturation 0.01 mg/L
±0.3mg/L or ±5%
OPR Intelligent Sensor LH-DR31 -2000~-2000mV lmV ±15%
COD Intelligent Sensor LH-DC18 0~600mg/L equiv.KHP 0.1mg/L ±5%F.S
Chlorine Dioxide Intelligent Sensor LH-E900 Chlorine Dioxide:0-20.00mg/L Temperature:-10.0~110.0℃ Chlorine Dioxide:0.01mg/L Temperature:0.1℃
Chlorine Dioxide:±0.1 mg/L
Temperature:±0.5℃
Residual Chlorine Intelligent Sensor LH-F900 Residual Chlorine:00.00mg/L~20.00 mg/L
Temperature:-10.0~110.0℃
Residual Chlorine:0.01 mg/L
Temperature:0.1℃
Residual Chlorine:±0.1mg/L
Temperature:±0.5℃
Ammonia Nitrogen Intelligent Sensor LH-N100 0-100mg/l(phcompensation 4-10) 0.1mg/l
±5%F.S.or±3mg/l,take greater as standard
Nitrate Intelligent Sensor LH-NO3 Nitrate:0.1-14000ppm(or mg/L) Temperature:0.0~50℃
pH:2.5~11pH
Nitrate:0.01
Temperature:0.1℃
Measuring standard solution±5%
Chlorophyll Intelligent Sensor LH-T615 0~500µg/L 0.1 µg/L ±5%
Blue-Green Algae Intelligent Sensor LH-T613 0-200, 000 cells/mL 1 cells/mL ±5%
Ozone Intelligent Sensor LH-DZ900 Ozone:00.00mg/L~20.00 mg/L Temperature:-10.0~110.0℃ Ozone:0.01 mg/L Temperature:0.1℃
Ozone:5%F.S.
Temperature:±0.5℃

Online Multiparameter Universal Controller | LH-D6901

Brand

Lohand
