Ultrasonic Level Transmitter – Overview

This non-contact ultrasonic level transmitter ensures virtually maintenance-free measurement. The measurement is unaffected by media properties such as dc value or density and can be calibrated without filling or discharging. It is also self-cleaning due to its vibrating sensor diaphragm. The sensor pulses a signal in the direction of the product surface. The signal is then reflected back and received by the sensor which converts it into a reading of the level of the liquid or solid level. Applications include storage tanks, chutes, pools, wells, drains, metering boxes, granaries etc.

Ultrasonic Level Transmitter – Features

• Level Range: 4,6,8,10,12,15,20,30m
• Accuracy: 0.5%-1.0%
• Resolution: 3mm or 0.1%
• Display: LCD Display
• Analog Output: Two Wires 4-20mA/250Ω Load
